1MB1300SA-120B-52 1200V 1300A Half-Bridge IGBT Module Low Vce(sat) High Short Circuit Ruggedness Low Switching Loss Press-Fit Technology For Heavy Industrial Drives and High Power UPS

1MB1300SA-120B-52 1200V 1300A Half-Bridge IGBT Module Low Vce(sat) High Short Circuit Ruggedness Low Switching Loss Press-Fit Technology For Heavy Industrial Drives and High Power UPS

Features

• Ultra-High Power Half-Bridge Module: 1200V / 1300A

• Advanced High-Current IGBT and Diode Chips

• Very Low Vce(sat) (Extremely Low Conduction Loss)

• Optimized Low Switching Losses

• Very High Short-Circuit Ruggedness (SCWT)

• Low-Inductance Design

• Press-Fit Contact Technology

• Integrated Temperature Monitoring (NTC)

• Designed for High Reliability and Easy Maintenance

Applications

• Heavy Industrial Drives: For very large motors in metal rolling mills, mining excavators, and large compressors.

• High-Power Uninterruptible Power Supplies (UPS): For mega data centers and critical industrial facilities.

• Power Conversion Systems (PCS) for large-scale battery energy storage stations (BESS).

• High-Power Test Benches and Grid Simulators.

• Renewable Energy Inverters for utility-scale projects.

Description

The 1MB1300SA-120B-52 is an ultra-high-current half-bridge IGBT module engineered for megawatt-level power conversion in the most demanding industrial applications. It delivers a high voltage rating of 1200V combined with an exceptional current capability of 1300A. Utilizing the latest generation of IGBT and diode chips, it achieves an excellent balance of very low collector-emitter saturation voltage (Vce(sat)) for minimal conduction losses and optimized switching characteristics for high efficiency. The module is built for ultimate ruggedness and reliability, featuring very high short-circuit withstand capability, low internal inductance, and Press-Fit contact technology for robust, solder-free, and maintenance-friendly power connections, ensuring maximum uptime in critical systems.
