MJD41CT4G 100V 41A NPN Darlington Power Tab MOSFET Low Vce(sat) High Gain Fast Switching Built-in Clamp Diode TO-220 Package for Easy Mounting

MJD41CT4G 100V 41A NPN Darlington Power Tab MOSFET Low Vce(sat) High Gain Fast Switching Built-in Clamp Diode TO-220 Package for Easy Mounting

andnbsp;

Features

andbull;Lead Formed for Surface Mount Applications in Plastic Sleeves (No Suffix)

andbull;Straight Lead Version in Plastic Sleeves (andldquo;1andrdquo; Suffix)

andbull;Electrically Similar to Popular TIP41 and TIP42 Series

andbull;Epoxy Meets UL 94 Vandminus;0 @ 0.125 in

andbull;NJV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AECandminus;Q101 Qualified and PPAP Capable

andbull;These Devices are Pbandminus;Free and are RoHS Compliant

andnbsp;

Applications

Linear voltage regulators and power amplifiers

Speed/direction control for DC and stepper motors

Drivers for solenoids, high-power relays, and actuators

Inverters and Switch-Mode Power Supplies (SMPS)

Various high-current switching circuits in automotive and industrial fields

andnbsp;

Description

1:High Power Handling: Features a 100V collector-emitter voltage (VCEO) and a 41A continuous collector current (IC), enabling it to drive high loads.

2:Darlington Configuration: Provides very high DC current gain, allowing control of large load currents with a very small base drive current, which simplifies driver circuit design.

3:Low Saturation Voltage: A typical VCE(sat) of only 1.0V at IC=20A and IB=40mA helps minimize power loss and heat generation during the on-state, improving overall efficiency.

4:Fast Switching Speed: The optimized Darlington design offers relatively fast switching performance, suitable for switch-mode power supplies, motor control, and other applications requiring frequent switching.

5:Built-in Clamp Diode: Includes an integral flyback diode that effectively suppresses reverse electromotive force (back-EMF) generated by inductive loads (e.g., motors, relay coils), protecting the transistor from voltage spikes and enhancing system reliability.

6:Robust TO-220 Package: This package offers good mechanical strength and thermal performance, facilitates the attachment of a heat sink for high power dissipation, and ensures stable operation in high-temperature environments.

7:Lead-Free andamp; RoHS Compliant: Meets environmental regulation requirements.

andnbsp;

INFORMATION

andnbsp;

Drawing

Our advantage :phones, PDAand#39;s, notebook comput.ers

• High quality products --- our offers are 100% new and original, ROHS
• Competitive price --- good Purchase channels with good price.
• Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
• Adequate inventory --- With the support of our strong Purchasing team,
• Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.

andnbsp;

be sure to meet your need for all kinds of components. ^_^
